    SB147 Nut Through Bolt for Hydraulic Breaker Spare Parts Long Bolts SB147 Hydraulic Breaker Through Bolt

    Ask Lasest Price
    Brand Name : Huilian
    Model Number : XL1600 XL1700 XL1900
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T, MoneyGram
    Supply Ability : 10000 PCS per week
    Delivery Time : 1-7days
    • Product Details
    • Company Profile

    SB147 Nut Through Bolt for Hydraulic Breaker Spare Parts Long Bolts SB147 Hydraulic Breaker Through Bolt

    SB147 Nut Through Bolt for Hydraulic Breaker Spare Parts Long Bolts SB147 Hydraulic Breaker Through Bolt

    Product NameHydraulic Breaker Bolt
    Materials40Cr,42CrMo
    Advantages1).Powerful impact strike
    2).Stronger wear resistance
    3).Longer durability
    4).Suitable for most breaker hammer
    Manufacturing ProcessForging→Turnery→Heat treatment→Ultrasonic flaw detection→Hardness test
    Applicable ModelsSB147

    Hydraulic hammer bolts
    The penetration bolt on the crushing hammer is a key fastener, which plays an important role in the overall structure of the crushing hammer. This specially designed bolt not only carries the task of connecting the various parts of the structure, but also is responsible for maintaining the stability and safety of the crushing hammer in harsh working environments.
    Penetration bolts are typically made of high-strength alloy steel, which has excellent tensile, shear and fatigue resistance to maintain their integrity and reliability under extreme operating conditions. The surface is usually treated with special treatment, such as galvanized or sprayed with anti-corrosion coating, to improve the corrosion resistance of the bolt and extend its service life.

    In a crushing hammer, the main role of the through bolt is to firmly connect the hammer head to the hammer body, while allowing for removal for repair or replacement of parts if necessary. Its design takes into account both the huge impact and vibration generated by the crushing hammer while working, and to ensure the sealing of the connecting part to prevent the infiltration of liquid or solid particles leading to damage to the internal parts.


    WHY CHOOSE US
    ➤Own Design and Technology

    ➤Best Quality and Service

    ➤Global Enterprise

    ➤Various Model Line-up

    ➤Excellent Crushing Strength

    ➤Beyond Comparison In Terms of Solidness


    Recommend Products

    Through/Side BoltSB40 SB43 SB45 SB50 SB60 SB70 SB81 SB100 SB121 SB131 SB141 SB151
    Chisel RodHB15G 20G 30G 40G F22 F35 F45
    Inner Outer BushingEDT400 EDT435 EDT800 EDT2000 EDT2000F EDT2200A EDT3500F EDT4500
    Rod PinGB1T GB2T GB3T GB4T GB6T GB8T GB11T GB175 GB180 GB630E GB210D
    PistonRHB305 RHB313 RHB322/325/326 RHB323/321 RHB330 RHB324/326 RHB180
    Piston RingTNB5M TNB7E TNB7J TNB16B TNB141 TNB150 TNB151 TNB190 TNB230 TNB310
    Reversing Control ValveTHBB801 THBB1400 THBB1600 THBB175L THBB190
    AccumulatorBLTB40 BLTB45 BLTB53 BLTB70 BLTB75 BLTB190 BLTB200 BLTB205 BLTB210
    Nitrogen Gas Charging ValveSB40 SB43 SB45 SB50 SB60 SB70 SB81 SB100 SB121 SB131 SB141 SB151
    Nitrogen Gas Charger KitHB15G 20G 30G 40G F22 F35 F45
    Oil Seal KitEDT400 EDT435 EDT800 EDT2000 EDT2000F EDT2200A EDT3500F EDT4500
    Rubber DiaphragmGB1T GB2T GB3T GB4T GB6T GB8T GB11T GB175 GB180 GB630E GB210D
    Cylinder Front HeadRHB305 RHB313 RHB322/325/326 RHB323/321 RHB330 RHB324/326 RHB180
    Cylinder Back HeadTNB5M TNB7E TNB7J TNB16B TNB141 TNB150 TNB151 TNB190 TNB230 TNB310
    CylinderTHBB801 THBB1400 THBB1600 THBB175L THBB190
    Main BodyBLTB40 BLTB45 BLTB53 BLTB70 BLTB75 BLTB190 BLTB200 BLTB205 BLTB210
    Triangle Type BreakerSB40 SB43 SB45 SB50 SB60 SB70 SB81 SB100 SB121 SB131 SB141 SB151
    Excavator Box Silenced TypeHB15G 20G 30G 40G F22 F35 F45

    We Can Provide Following Hydraulic Breaker Models

    Hammer PartsMain BodyBack HeadCharging ValveCylinder
    Socket PlugPistonAdapterValveValve Plug
    Front HeadGrease NippleRod PinStop PinRubber Plug
    Ring BushThrust BushUpper BushFront CoverTool Bush
    Rod Moil PointChiselWasherThrough BoltSide Rod
    Air Check ValveValve AdjusterAccumulatorAccumulator BodyAccumulator Cover
    Charging V/VDiaphragmSeal KitO-Ring SealGas Seal
    Buffer SealDust SealU-PackingBack-up ringSide Bolt
    Down CushionTool SetN2 Gas Charging SetN2 Gas CylinderB-3way valve assy
    Seal RetainerValve SleeveFront Head PinLower BushHex Nut
    Socket BoltStep SealUpper CushionRubber PadShock Absorber

    Product Specification

    Modelthrough boltsside boltsModalthrough boltsside bolts
    HB8GM27*635M30*282SB10M20*445M16*190
    HB10GM33*738M36*380SB20M22*490M18*200
    HB15GM36*815M42*420SB30M24*525M20*190
    HB20GM42*970M48*450SB35M24*555M24*200
    HB30GM48*1050M48*510SB40M27*575M27*230
    HB40GM52*1150M56*520SB43M30*710M30*260
    HB50GM60*1524M60*620SB45M33*840M30*280
    FX15GM36*830M42*420SB50M39*885M36*310
    FX220M42*956M48*454SB60M42*976M48*410
    FX270M50*1030M48*454SB70M48*1022M48*450
    FX360M55*1095M55*489SB81M52*1050M48*440
    FX470M62*1190M60*569SB100M56*1120M56*490
    F12M33*755M36*380SB121M56*1150M56*510
    F19M39*800SB130M56*1210M56*520
    F35M50*1066M48*1050SB131M56*1225M56*530
    F45M48*1050M48*1050SB140M58*1300M58*560
    FX700M48*1050M48*1050SB151M56*1370M56*560
    FHB190M48*1050M48*1050SB147M58*1357M56*540
    FX190M48*1050M48*1050SB177M85*1650
    B1TM24*530TNB5MM24*580
    GB2TM27*585TNB7EM36*760
    GB3TM30*610TNB7IM36*342
    GB4TM33*805TNB16BM48*1190
    GB6TM42*976TNB141M42*920
    GB8TM52*1052TNB150M42*1010
    GB11TM56*1150M56*516TNB151M48*421
    GB175M58*1390M58*600TNB190M48*1080
    GB180M60*1540TNB230M52*1210
    GB630EM60*1540TNB310M52*1260
    GB210DM70*1658THBB401M27*588
    RHB305M27*580THBB801M36*765
    RHB313M36*812M36*330THBB1400M40*1265
    RHB322/32M42*1160THBB1600M46*1250
    RHB323/32M42*1080THBB175LM60*1500
    RHB330M50*1240THBB190M60*1700
    RHB324/32M42*1086
    RHB180M60*1500
    Modalthrough boltsside boltsModalthrough boltsside bolts
    TSK155M52*1310M52*510MKB1500V1M40*1037M42*380
    TSK210M40*975MKB1500V2M40*1057M42*426
    TSK220M42*1080S2200M42*1086M42*435
    TSK300M52*1270DWB3700M48*1035M48*520
    HM960M35*950SG2800M56*1160M60*495
    S1300M36*900XB12GM36*365
    F19M39*800CMB80TM52*473
    OUB312M40*950DAEW5000M52*1170M52*540
    TR210M40*965M42*441KB450GM52*1140M52*600
    SG400M24*350Kangsan121M60*520
    SG2100-1M40*1004JSB43TM30*607
    SG2100-2M40*1008B360M58*1300
    SG2100-3M40*1014EHB-30M52*1255
    MKB1500M42*486

    FAQ

    Q: Are you a manufacturer ?
    A: Yes, our factory was established in 2011.
    Q: Are you sure your product will fit my excavator?
    A: Our hydraulic breakers are suitable for most excavator. Show us your excavator model, we'll confirm the solution.
    Q: How about your products warranty?
    A: 12 months warranty for hydraulic breakers and 3-6 months for spare parts.
    Q: Can you produce according to customer's design?
    A: Sure, OEM & ODM service available. We are professional manufacturer in Guangzhou.
    Q: What's the MOQ and payment terms?
    A: MOQ of hydraulic breaker is 1 set. Payment via T/T, Western Union accepted, our terms can be negotiated.
    Q: How about delivery term ?
    A: 5-15 working days after payment.
    Q: How about the package?
    A: Our hydraulic breakers wrapped by stretch film, packed by pallet or polywood case, or as requested.
    Q: Which country have you exported?
    A: Saudi Arabia, Korea, Thailand, Cyprus, India, Canada, Australia, Peru, Egypt, Brazil, Mexico, South Africa, etc
